HIKVISION DS-3E0524-E(C) 24 Port Gigabit Unmanaged Desktop Switch 24x 10/100/1000 Mbps, 6942160469782
HIKVISION DS-3E0524-E(C) 24 Ports Ethernet Gibabit Switch plug & play, 24 x 10/100/1000, 48Gbps Switching Capacity, μεταλλικό περίβλημα, ενσωματωμένο τροφοδοτικό 230VAC. Περιλαμβάνει καλώδιο τροφοδοσίας Σούκο και λάμες για στήριξη σε Rack
Βασικά Χαρακτηριστικά:
Network Parameters:
- Ports: 24 × Gigabit RJ45 port
- MAC Address Table: 8 K
- Switching Capacity: 48 Gbps
- Packet Forwarding Rate: 35.71 Mpps
- Internal Cache: 4.1 Mbits
General:
- Shell: Metal material, fan-free design
- Net Weight: 1.4 kg (3.1 lb)
- Gross Weight: 1.9 kg (4.2 lb)
- Dimensions (W × H × D): 440.00 mm × 44.00 mm × 160.00 mm (17.32'' × 1.73'' × 6.30'')
- Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F)
- Storage Temperature: -40 °C to 85 °C (-40 °F to 185 °F)
- Operating Humidity: 5% to 95% (no condensation)
- Relative Humidity: 5% to 95% (no condensation)
- Power Supply: 100-240 VAC, 50/60 Hz, Max. 0.7 A
- Max. Power Consumption: 18 W
- Power Consumption in Idle: 3.8 W
- Installation Mode: Rack (equipped with mounting ears)
- Surge Protection: 6 K
